How to Develop an Irrigation Schedule Using Cropwat 8.0
CropWat is a computer program developed by the Food and Agriculture Organization of the United Nations (FAO) to estimate irrigation requirements based on climate, crop and soil data. This is a widely used tool for estimating irrigation water requirements for practical field level use and it is also used for research purposes. In addition, the tool can be used for developing irrigation schedules for different management conditions and calculating water supply schemes for different cropping patterns. This article will guide you in how to calculate your own irrigation water requirements, enabling you to successfully develop an irrigation schedule.
Familiarizing yourself with the software
Download and install the software.Download CropWat 8.0 from FAO website and then install it. This program runs on the following Windows platforms: 95/98/ME/2000/NT/XP/7 and Vista.
- To get the software, visit .
Get familiar with the user interface.CropWat 8.0 has a user friendly interface that includes the following features:
- Using the ‘File’ menu, you can start a new session, open an existing session, save a session, close a session, open new input file (climate/ETo, Rain, crop, soil and cropping pattern), save an input or output file, print and exit.
- From the ‘Edit’ menu you can do basic cut, copy and paste operations.
- From the ‘Calculations’ menu you can calculate water requirements, develop schedule and calculate scheme supply.
- The buttons on the left side panel can also be used to create input files or perform calculations.
- Using the ‘Charts’ menu, you can create charts or graphs.
- Using the ‘Settings’ menu, you can change options of input and output files and change file locations.
- From the ‘Language’ menu, you can change the interface to either English, French, Russian or Spanish languages.
Inputting and collating climate data
Collect and input climate data.Click on the ‘Climate/ETo’ button on left side panel to input the collected climate data. CropWat uses daily, decade or monthly climate data to estimate reference evapotranspiration (ETo).
- If you want to calculate irrigation water requirements for any previous year, then you need to collect the climate data for that year from your nearest meteorological station.
- If you want to calculate irrigation water requirements for any future time then you need to collect future forecast data.
- If local climatic data are not available, you can obtain those data for over 5,000 stations worldwide from CLIMWAT (an associated climatic database).
Get the appropriate data.CropWat requires the following climate data:
- maximum and minimum temperature (°C) or average temperature (°C),
- relative humidity (%) or vapour pressure (kPa),
- wind speed (km/day or m/s),
- sunshine hour or percent of day length or fraction of day length.
Inputting and collating rainfall data
Collect and input rainfall data.Collect the rainfall data. Click on the ‘Rain’ button to input the collected rainfall data.
From the ‘Settings’ menu open the ‘Options’ and click on ‘Rainfall’ tab to select the method of calculating effective rainfall.The available options for calculating effective rainfall are:
- fixed percentage,
- dependable rainfall (FAO/AGLW formula),
- empirical formula, and
- USDA soil conservation service method.
Inputting and collating crop data
Collect and input crop data.Collect the required crop data. Click on the ‘Crop’ button on the left side panel to input the crop data. CropWat is suitable to estimate irrigation water requirements for both dry crops and rice.
Collect the following crop data for dry crops:
- planting date,
- Kc values at initial, mid-season and at harvest,
- number of days for initial, development, mid-season and late season,
- rooting depth (m),
- critical depletion (fraction) at initial, mid-season and late season,
- yield response factor at initial, development, mid-season and late season,
- crop height (m).
Collect the following data for rice (you need to collect some additional data):
- both Kc dry and Kc wet values at every stage,
- number of days for nursery and land preparation also,
- puddling depth (m),
- nursery area (%).
Inputting and collating soil data
Collect and input soil data.Collect the required soil data. Click on the ‘Soil’ button on the left side panel to input the soil data. CropWat requires the following soil data:
- total available soil moisture (mm/meter),
- maximum rain infiltration rate (mm/day),
- maximum rooting depth (cm),
- initial soil moisture depletion (as % TAM),
- initial available soil moisture (mm/meter).
Provide additional soil data for rice:
- drainable porosity (%),
- critical depletion for puddle cracking (fraction),
- maximum percolation rate after puddling (mm/day),
- water availability at planting (mm WD or % desat. or % depl.),
- maximum water depth (mm).
Estimating your irrigation water needs
Estimate your irrigation water requirements.After completing the previous steps, click on the ‘CWR’ button on the left side panel to estimate your own irrigation water requirements. Irrigation requirements are shown in mm/decade.
Get a climate/ETo/rain chart.Click on the ‘Charts’ menu, then click on ‘Climate/ETo/Rain’ to get a chart of the inputted climate variables. Below the chart you will see that there are options to select which variables you want to show on your chart. You can also select whether the variables will show as either a bar or a curve.
Get a crop water requirements graph.Click on the ‘Charts’ menu, then click on ‘Crop Water Requirements’ to get a graph of your crop water requirements. Within the same graph you can also get an ET crop by selecting the ‘ET crop’ option below the graph. You can also select whether those will show either as a bar or a curve.
Developing your irrigation schedule
Click on the ‘Schedule’ button on the left side panel to get a tailored irrigation schedule. By clicking on the 'Schedule' button, you will get a table of irrigation schedule and a table of daily soil moisture balance. You will get information on:
- total gross irrigation,
- total net irrigation,
- total irrigation losses,
- total percolation losses,
- actual water use by crop,
- potential water use by crop,
- effective rainfall,
- total rain loss,
- moist deficit at harvest,
- actual irrigation requirement, and
- yield reduction.
Click on the ‘Options’ button to modify the scheduling based on different irrigation timing, irrigation application system and irrigation efficiency.The available irrigation timing options are:
- irrigation at fixed water depth,
- irrigation at fixed % desaturation,
- irrigation at fixed % of critical depletion,
- irrigation at fixed WD/desaturation/critical depletion per stage,
- irrigation at fixed interval per stage,
- irrigation at given ET crop reduction,
- irrigation at given yield reduction,
- irrigate continuously,
- no irrigation (rain-fed).
Check the other available irrigation application options to see if these are needed too.These include:
- user defined application depth,
- refill to fixed water depth,
- refill to or below saturation,
- refill to or below field capacity,
- refill to fixed WD/saturation/FC,
- fixed application depth.
Get an irrigation schedule graph.Click on the ‘Charts’ menu, then click on ‘Irrigation Schedule’ to get a graph of your irrigation schedule. Below the graph you can select options (for example, depletion soil moisture, depletion saturated water, RAM root zone, TAM root zone, SAT root zone, TAM whole puddle and SAT whole puddle), which you can either show or hide in the graph.
QuestionWhat does "decade" mean in this context?TaposCommunity AnswerIn CropWat input files, "decade" indicates a 10 day interval. So, for example, "decade 1" of January means the first 10 days in the month of January.Thanks!
QuestionAfter giving all inputs like ET, rainfall, etc., can I get the results as a report?TaposCommunity AnswerYou can get the estimated values of different outputs along with graphs. (The outputs of the soil moisture balance are in tabulated form.)Thanks!
QuestionHow do I enter multiple crops?TaposCommunity AnswerYou can select multiple crop files using the Crop Pattern window. On left side panel, you can find the Crop Pattern button.Thanks!
QuestionHow do I input data daily using Cropwat?TaposCommunity AnswerIn a new Climate/ETo file, you can select Daily ETo Penman Monteith to input daily data.Thanks!
QuestionHow do I convert mm to bcm?TaposCommunity AnswerYou can input rainfall only in mm in CropWat. You can use other programs (e.g. Excel) to convert the units first, then use them as the input in CropWat.Thanks!
QuestionWhat are the advantages of using CropWat? What are other irrigation scheduling softwares I can use?TaposCommunity AnswerCropWat is a simple and user-friendly software. Standard datasets for different crop and soil type are available by FAO, which is convenient for different users. Some others models like DSSAT, CropSyst, Oryza can be used to estimated irrigation requirement, but those models do not focus on irrigation management or scheduling.Thanks!
QuestionWhere do I get the input data like related to crop data and soil data?TaposCommunity AnswerYou can get the input data related to crop and soil from the local agricultural and soil research institutes.Thanks!
QuestionHow can I input the data of Excel into Cropwat, such as climate data?TaposCommunity AnswerWe cannot open excel files in CropWat. You can copy your required data from excel and paste that to Cropwat.Thanks!
